GE240 Elephant Trunk Refuse Collection Vehicle
Catalog：
The whole machine adopts pure electric design, which is green, environmentally friendly, flexible and convenient. It is suitable for garbage collection in parks, squares, schools, docks, scenic spots, residential properties and other areas.
keyword：Snow Blade
Detail
PRODUCT FEATURES
Widely applicable The whole machine adopts pure electric design, which is green, environmentally friendly, flexible and convenient. It is suitable for garbage collection in parks, squares, schools, docks, scenic spots, residential properties and other areas. It uses vacuum negative pressure to collect garbage and can quickly suck in floating garbage such as bottles, cans, broken glass, leaves, and paper. It is especially suitable for picking up garbage piled up in dead corners on the roadside.
Performance characteristics The circular filter is easy to disassemble and has a larger filtering area.Directly connect to the 240L standard garbage bin for convenient garbage collection and dumping.
Adopting a large-diameter suction port, suitable for suctioning cans, bottles, broken glass, leaves, paper, lightweight materials, etc.
Adopting a hand pull multifunctional handle and a simple operating system, making it easier for users to operate.
This device is powered by a 48V maintenance free battery, which is energy-saving and environmentally friendly, and has a long continuous use time.
The front and rear are equipped with inflatable tires, ensuring smooth driving and easy disassembly of all mechanical components.
Small space occupation, low noise, small turning radius, and large cleaning freedom. High power vacuum motor with stable performance and strong suction force.
Adopting a large-diameter suction port, suitable for suctioning cans, bottles, broken glass, leaves, paper, lightweight materials, etc.
Adopting a hand pull multifunctional handle and a simple operating system, making it easier for users to operate.
This device is powered by a 48V maintenance free battery, which is energy-saving and environmentally friendly, and has a long continuous use time.
The front and rear are equipped with inflatable tires, ensuring smooth driving and easy disassembly of all mechanical components.
Small space occupation, low noise, small turning radius, and large cleaning freedom. High power vacuum motor with stable performance and strong suction force.
Technical Parameters
| Item | Item | parameter |
| Suction Diameter | mm | 110 |
| Working Radius | m | 3.2 |
| Wheelbase | mm | 1300 |
| Tread | mm | 750 |
| Demension(L*W*H) | mm | 2450*950*1800 |
| Weight | kg | 425 |
| Water Tank Capacity | L | 60 |
| Dustbin Capacity | L | 240 |
| Filtering Area | m2 | 9 |
| Driving Speed | km/h | 0~6 |
| Turning Radius | mm | 1450 |
| Climbing Capacity | % | 20 |
| Power Supply | V | 48 |
| Driving Power | W | 2200 |
| Dust Absorption | W | 1500 |
| Working Time | h | 4~6 |
| Dust reduction pump flow rate | L/min | 3 |
| Dust reduction pump pressure | Mpa | 0.5 |
| Sterilization pump flow rate | L/min | 19 |
| Sterilization pump pressure | Mpa | 0.5 |
